Designed for clamping to a receiver dovetail.
These economical mounts are still manufactured with the same precision as our top of the range model, the pivot mount
Specifically designed for small caliber rifles with dovetail
Outstanding compensation for weapon tolerances
Tension-free horizontal scope mounting
Body and ring caps made of aluminium with dovetail clamping jaw made of steel.
| Tube Diameter: | 30mm |
| Height (BH): | 17mm |
| Ring Width (RB): | 15mm |
| Extension (KR): | |
| Dovetail: | 11mm |
| Material: | Aluminum/Steel |
| Finish: | Matte |
Item Nr.: 318-470003017011
